WPC Floor Production Line with embossing machine

  • WPC Floor Production Line with embossing machine
  • WPC Floor Production Line with embossing machine
  • WPC Floor Production Line with embossing machine
  • WPC Floor Production Line with embossing machine

WPC Floor Production Line with embossing machine

    Brand: Langbo
    Transportation: Ocean,Land
    Place of Origin: Jiangsu, China
    Certificate: CE
    Port: Shanghai

Product Description

Indoor WPC Floor Production Line


ADVANTAGES OF WPC COMPOSITES :

WPC (Wood Plastic Composites) is one of the natural fiber composites.

Because of its durability, natural fiber composites are increasingly replacing pure natural products in many application areas, for example, decking products, fence components or screening walls. Langbo Machinery supplies complete system solutions for the applications.

PVC is an extremely versatile material that is generally available as a dry (powder) blend. Prior to processing in the extruder, additives are blended into the virgin PVC in a heating/cooling mixing unit. PVC compounds are sensitive to shearing and high temperatures and are therefore gently processed on either parallel or conical twin screw extruders, depending on throughput requirements

Conical Twin Screw Extruder is widely used to process natural fiber-rein-forced plastics such as WPC (wood plastic composites). With an optimized design and logic combination of core components our Extrusion Line has other benefits such as stable material feeding, gentle, non-destructive processing and highly stable screw pressure for the production. So that the homogeneous melt wit optimum temperature will be extruded.



Wpc Profile3 Jpg

STRUCTURE OVERVIEW OF PRODUCTION LINE

  • Tooling
  • Calibrating table
  • Haul-off
  • Cutting unit
  • Tip table


Production Process:

Raw material +wood power+ additive ~ mixing ~granulating ~ conical twin-screw extruder ~ profile extrusion mould~ cool molding die ~ vacuum calibration support ~ belt haul-off ~cutter ~ rack ~ finished product inspecting & packing



Extrusion Profile19




SPECIFICATION:


The Table provides a general information for standard Product.

For Further customized technical assignment please contact us.


Model SJZ45 SJZ51 SJZ65 SJZ80 SJZ92
Screw diameter (mm) 45/100 51/105 65/132 80/156 92/188
Screw rotation speed (r/min) 4-45.5 1-30 1-34.7 1-36.9 1-32.9
The effective length of the screw (mm) 1000 1050 1430 1800 2520
Main motor power (kW) 15 22 37 55 90
Barrel heating power (kW) 12 18 24 36 48
Capacity (kg/h) 95 110 250 380 520
Central height (mm) 1000
Net Weight(kg) 3000 3200 5000 6500 7500


Haul Off Cutting Combination









Zhangjiagang Langbo Machinery Co. Ltd.



ZHANGJIAGANG LANGBO MACHINERY CO., LTD. is a continually growing and forward-thinking firm focusing on the range of plastic extrusion and recycling processes.Due to our constant applying to plastic extrusion and recycling technology, we have mature competence to offering production lines for PVC/PE/PP-R pipe, PE/PP-R composite multi-layer pipe, PVC profile, PVC/PP/PE composite profile, PVC compounding and recycling for PET/PP/PE or other wasted plastics.

With the aim of delivering a personal tailored, efficient and professional service to fulfill our lang-standing and new customer requirements. We provide not only our high quality standard or customized equipment but also our comprehensive services including machinery operation and maintenance guidance. In the fast-growing competitive market, we helped our customers to achieve their business goal and expanded our production capabilities and warehousing significantly.
